10 Ports Docking Station
SIZE GUIDE
SIZE | XS | S | M | L | XL | XXL |
---|---|---|---|---|---|---|
BUST | 88 | 89 | 90 | 91 | 92 | 93 |
WAIST | 55 | 56 | 58 | 59 | 62 | 65 |
HIPS | 90 | 92 | 94 | 95 | 96 | 98 |
SIZE | XS | S | M | L | XL | XXL |
---|---|---|---|---|---|---|
BUST | 60 | 62 | 65 | 66 | 68 | 69 |
WAIST | 50 | 55 | 58 | 62 | 65 | 66 |
HIPS | 80 | 82 | 85 | 86 | 88 | 89 |
Description
Docking Slot
The charging slot adopts cabin type dock design
Docking Slot Number
10 pcs
Indicator Light 1
The red light LED is the power indicator, the red light will be on after power on
Indicator Light 2
Green LED lights up after detecting a successful connection, and flashes when data is being transmitted
Switch
Rocker switch, main power switch with light
Power on Switch
Power on switch M16 with lock and light
AC Socket
AC socket, national standard
Product Material
Use sheet metal integrated chassis, paint, integrated independent design; the shell material is 1.0mm cold rolled steel plate, and the surface is treated with anti-static powder coating
Support automatic Charging (when body worn camera connect to docking station)
The charging current is 1A-1.5A, supporting charging protection
Data Line
Compatible with mainstream data lines such as MINI USB, Apple, Micro USB, Type-c, etc
Support Charging Protection
Hardware automatic detection function, automatically disconnect the charging channel when the battery is full
Reliability Test
MTBF≥20000h
Fuse
220V 2A
USB Interface
USB 2.0 HUB, transmission rate ≥400M/min
Operating Temperature
-10˚C ~ 50˚C Surface air flow
Storage Temperature
-20˚C ~ 60˚C
Storage Humidity
95%@40˚C
Dimension
320mm x 250mm x 100mm
Weight
9.7kg
