DG-MC5123P – Digisol 100Base-FX Single Mode PoE Media Converter
DIGISOL This 10/100M PoE media converter can be use between 10Base-T and 10Base-FL or 100Base-TX cable and 100Base-FX fiber cable for data transmission. It provides stand-alone RJ-45 electrical interface port and supply power to others, and can automatically cross connection with switch and hub network. Plug and play design makes easy installation, no on-site adjustment, all the light, electrical interface port is in line with international standards and feature with link loss diagnosis, electrical port link diagnosis and optical port link diagnosis, dynamic data transmission, full-duplex/half-duplex, speed indicator. Also it can be realize the interconnection between motherboard servers, Repeaters, hubs, switches terminal.
KEY FEATURES
Supply power to Cat5 Ethernet network surveillance cameras
Broadcasting filtration function, automatic recognizing and modifying address with Store-and-transmission operational mechanism
Ethernet 10base-T or 100Base-TX 100Base-FX fiber media transmission
Compatible with IEEE802.3af, IEEE802.3, IEEE802.3U, IEEE802.3X, IEEE 802.3z/AB, IEEE802.1d standard
The electrical interface port supports 100Mbps, 10Mbps, both ends can use different speed (full-duplexwork bandwidth for line-speed 2XMbps)
Cache size for 512KB, address table size is 4KB
1x RJ45 port and 1x PoE port; Max each PoE port power is 15.4W
