Name: Media converter Gigabit 10/100/1000
Brand: Match LB-Link
SKU: 10167
Availability: InStock

On Sale!

Original price was: ₹3,800.00.Current price is: ₹1,799.00.

Gigabit Media Converter- 10/100/1000 | Match
BL-MC20SFG

10/100/1000 BASE-TX TO 1000 BASE FX

Match Gigabit Media Converter 10/100/1000 enables to connect two dissimilar networks. It is used to link fiber optic cable to twisted pair for supporting ethernet-compatible devices.

[ Gigabit 10/100/1000Mbps Speed ]

This Gigabit media converter provides the fastest speed of 10/100/1000Mbps. It supports which meets the standards of IEEE802.3, 802.3u, 802.3x.
It can conduct mutual conversion between 10Base-T/100Base-TX twisted-pair electrical signal.

[ Auto Negotiation ( 802.3ab) ]
Match Gigabit media converter supports auto negotiation of Automatic full-duplex and half-duplex conversion.

[ Fast and Stable transmission ]

This Media Converter provides faster and more stable transmission. Also, It can provide hot swappable power protection. It extends the transmission distance of a network from 100m over copper wires to 20Km.

[ Easy Set up and Installation ]
It is very easy to set up this Media Converter. You need to just plug and play. This media converter provides average trouble-free usage of more than 50000 hours. It also accords with standard telecommunication level operation.

[ LED Indicators ]
It has LED indicators to know what is active in this 10/100Base TX to 100 Base FX bridging converter. It has active adopted four layers circuit structure, stable work, smooth data transmission, the anti-interference ability.

[ Other Features ]
* Supports SPANNING TREE structure fault-tolerant network
* Support hot swaps
*Automatic full-duplex and half-duplex conversion
* With the German Siemens surface welding assembly lines processing
*Make in India with 3 Years of warranty

Technical Specification

100 BaseFX
1000 BaseFX

Band Width
IEEE802.3,802.3u,802.3x

RJ 45 Port
10/100 BaseT(X)
10/100/1000 Base T(X)

Wavelength
850nm/1310nm/1550nm

Fibre Port
100BaseFX

Optical Fibre

100 BaseFX
1000BaseFX

Multi-Mode
Single-Mode
Multi-Mode
Single Mode

Distance
2km, 1310nm
25km, 1310nm
500m, 850nm
2km, 1310nm
25km, 1310nm

Max
-20dBm
-10dBm
-10dBm
-10dBm
-10dBm

Min
-14dBm
-3dBm
-3dBm
-3dBm
-3dBm

Sensitivity
<-18dBm <-30dBm <-18dBm <-18dBm <-22dBm Power Requirements and Environmental Limits 100BaseFX 1000BaseFX Input Voltage 5V Power 5W Operating Temperature -20 ~ +70°C Storage Temperature -40-+85°C Ambient Relative Humidity 5-95% (non-condensing) Other Details 100BaseFX 100BaseFX Internal power supply With 2 RJ-45 External power supply With 4 RJ-45 Internal power supply External power supply Dimensions (mm) 94x70x25 140x110x30 215x110x30 94x70x25 140x110x30 Weight(g) 148 400 666 148 400 Out carton Dimensions(mm) 240x120x58 230x160x70 295x175x95 240x120x58 230x160x70 Out carton Weight(g) 396 685 1055 396 685 Download EDM Download Datasheet Check Out the Media converter with 100 Base FX.
